Run-on Landing Wearplates Fits LH or RH

Part Number: D350-636-047
Aircraft Models: Airbus - AS350

Price:
Login to see prices
DART traditional Wearplates and Wearpads are designed for durability under normal wear conditions. However, training and run-on landings present unique requirements for durability far in excess of normal operations. Our Run-on Landing Wearplates are specially designed for the harsh use of training and run-on landings. DART Run-on Landing Wearplates feature an easy thru-bolt installation which makes installation or replacement quick and easy and eliminates clamps over ... Read more
DART traditional Wearplates and Wearpads are designed for durability under normal wear conditions. However, training and run-on landings present unique requirements for durability far in excess of normal operations. Our Run-on Landing Wearplates are specially designed for the harsh use of training and run-on landings. DART Run-on Landing Wearplates feature an easy thru-bolt installation which makes installation or replacement quick and easy and eliminates clamps over the skidtube. The thru-bolt design also prevents the wearplate from rotating on the skidtube. Our Run-on Landing Wearplates are LH/RH interchangeable which reduces spares inventory. DART Run-on Landing Wearplates are constructed of corrosion- resistant stainless steel and feature a full length stainless steel wear bar with areas of generously overlaid highly wear resistant tungsten carbide and are installed with a corrosion- resistant compound between the skidtube and wearplate (no gaskets or sealant required). *Compatible on DART p/n D350-636-011/-012/-013/-014/-015/-016/-017/-018/-215/-216/-217/-218 Skidtubes. Includes stainless steel wearplate with heavy duty tungsten carbide training weld, and associated hardware. May be installed with or without floats. Not compatible with D350-636-107A/-107B Cable Guards. Not compatible with D350-578-011/-021 Bearpaws. Compatible with D350-578-015/-017 Bearpaws. Price is per skidtube. Read less

Description

DART traditional Wearplates and Wearpads are designed for durability under normal wear conditions. However, training and run-on landings present unique requirements for durability far in excess of normal operations. Our Run-on Landing Wearplates are specially designed for the harsh use of training and run-on landings. DART Run-on Landing Wearplates feature an easy thru-bolt installation which makes installation or replacement quick and easy and eliminates clamps over the skidtube. The thru-bolt design also prevents the wearplate from rotating on the skidtube. Our Run-on Landing Wearplates are LH/RH interchangeable which reduces spares inventory. DART Run-on Landing Wearplates are constructed of corrosion- resistant stainless steel and feature a full length stainless steel wear bar with areas of generously overlaid highly wear resistant tungsten carbide and are installed with a corrosion- resistant compound between the skidtube and wearplate (no gaskets or sealant required). *Compatible on DART p/n D350-636-011/-012/-013/-014/-015/-016/-017/-018/-215/-216/-217/-218 Skidtubes. Includes stainless steel wearplate with heavy duty tungsten carbide training weld, and associated hardware. May be installed with or without floats. Not compatible with D350-636-107A/-107B Cable Guards. Not compatible with D350-578-011/-021 Bearpaws. Compatible with D350-578-015/-017 Bearpaws. Price is per skidtube.

Key Features

  • LH/RH interchangeable
  • Compatible on DART Skidtubes
  • Stainless steel hardware

Key Benefits

  • Improved wear resistance
  • Innovative thru-bolt design eases wearplate installation and removal for inspection/replacement
  • Reduced need for spares inventory
  • Installs without messy sealant
  • Ideal for training operations

Approvals

Approval type Authority Reference number Aircraft approved Description
STC EASA - Europe 10033942 AS350B/AS350B1/AS350B2/AS350B3/AS350BA/AS350D/AS355E/AS355F/AS355F1/AS355F2/AS355N/AS355NP D350-636 Approved OEM Replacement Skidtube
STC ANAC - Brazil 2009S05-01 AS350B/AS350B1/AS350B2/AS350B3/AS350BA/AS355F/AS355F1/AS355F2/AS355N D350-636 Approved OEM Replacement Skidtube
STC TCCA - Canada SH99-7 AS350B/AS350B1/AS350B2/AS350B3/AS350BA/AS350D/AS355E/AS355F/AS355F1/AS355F2/AS355N/AS355NP D350-636 Approved OEM Replacement Skidtube
STC FAA - USA SR00646SE AS350B/AS350B1/AS350B2/AS350B3/AS350BA/AS350D/AS355E/AS355F/AS355F1/AS355F2/AS355N/AS355NP D350-636 Approved OEM Replacement Skidtube

OEM Cross References

N/A

External Warning

May be installed with or without floats.

Prerequisite

N/A

Compatible With

Bearpaws: D350-578-015/D350-578-017; DART Skidtubes: D350-636-011/-012/-013/-014/-015/-016/-017/-018/-215/-216/-217/-218

Not Compatible With

Bearpaws: D350-578-011/D350-578-021; Cable Guards: D350-636-107A/D350-636-107B

Flight Restrictions

None

Installation Time

1 hr

Dimensions And Weight

  • Length: N/A
  • Width: N/A
  • Weight Display: 3.30 lbs / 1.50 kg

Load Capacity And Volume

  • Volume: N/A
  • Load Capacity: N/A

Technical Documentation

Downloads

N/A
